RadioLink R6DSbus 2.4Ghz 6 Channel Sbus Receiver
DragonRC  RadioLink R6DSbus 2.4Ghz 6 Channel Sbus Receiver



Alternative Views:




Our Price: $36.00 Inc GST

Stock Status:In Stock
Product Code: RL-R6DS
Qty:

Description


R6DSbus - 3ms response time
Specification:

1. Channels: Red LED indicator Sbus/PWM mode. Blue LED for PPM, can be extended to 10channels

2. Power input: MAX 6V

3. Control distance: 600 meters or even farther beyond your sight

4. Current consumption: 38-45mA (Input voltage:5V)

5. Size: L×W×H=25×16×11mm

6. Weight: 3.9 grams

7. Precision: 4096


Features

R6DS is the newest and smallest 6 channels Sbus receiver of Radiolink.

R6DS can output PPM and Sbus/PWM double signals simultaneously, powered with DSSS frequency-hopping technology.

※ R6DS redefined dual signal mode----in an evolution way of R6DS that PWM and S.BUS output simultaneously, it provides operating modes PWM and PPM signal output.

Two operating modes output:

1) Sbus/PWM output.

2) PPM output, CH1 output PPM signal for 10 channels, and channel 2 to channel 6 output independent PWM signal simultaneously.

※ All channels response parallel, totally 3ms.

※ Specially used for light drones, compatible with all flight controllers such as DJI NAZA, ZERO TECH, PIX, APM, MINI APM, NAZE32, and CC3D etc.

※ One single cable connect with the flight controller, easy setting.

※ Total weights 3.9 grams, never burden to your drones.

※ Sub miniature size, best choice for light drones.

Product Feature:

1.DSSS act perfect on anti interference, especially on 433 and graph transmission.

2. Output by PPM and PWM double signals simultaneously.

3. Signal strength telemetry.

4. Top speed response, 3ms for all channels parallel.

5. Top precision 4096, 0.25us every bit insure every servo stable.

6. MAX voltage input is 6V.

7. MINI size, easy installation.
