VSpeak Modell Onboard Compressor Auto Air Fill for Air Retracts
VSpeak Modell - DragonRC Onboard Compressor Auto Air Fill for Air Retracts



Alternative Views:


Arriving very soon.
Pre-order now.
Our Price: $333.00

Stock Status:In Stock
Product Code: VS-OBCAR
Qty:

Description


There are several operating modes for Auto-Air-fill:

    • Autonomous Automatic mode (remote control independent)

    • Automatic mode Servo port (requires a servo output to which a 3-position switch has been programmed)

    • Automatic mode Telemetry port (only with Jeti and PowerBox core: Telemetry data are transferred)

The control of the onboard compressor can be delivered in 2 different versions:

    • BATT

    • OPTO

... which differ in that in the OPTO variant, the power section (i.e. motor + battery) and control section are isolaed from each other by means of an opto coupler.

The OPTO variant should always be selected if the compressor is to be driven by the turbine battery at the same time, which in turn is connected to a turbine ECU with isolation so that the desired potential separation is not canceled by the compressor control.

ECU's with electrical isolation: JetCat V6, V10 ,..., HORNET2, HORNET3, ... , evoJet, Jakadofsky, AMT, SWIWIN, ...

With the BATT variant, the negative poles of the power section and control section are connected to one another, monitoring of the battery voltage and protection against deep discharge are possible.
A detailed manual is available.
